Auto Strapping Machine [A9 Series]
Description
A-93 is designed for general applications with its reputation since years. Various arch size combination and workability of different strap widths between 9 ~ 15 mm can serve all kinds of packages. Tension range between 15-70 KGs and cycle speed 24 straps/min performed thru AC motor driven.
Features
• Hinged table top
• Proximity cam switch
• Instant heating system
• Modular arch component
• Weld cooling time adjustable
• Available for both PP & PET strap (specified)
• Digital regulator in PCB with LED show I/O status
Specification
| Speed | 24 strap / min |
| Strap Width | 9, 12, 15 mm (specified) |
| Tension Range | 15 ~ 70 kgs |
| Standard Arch | 850.W x 600.H mm |
| Motor | AC |
| Sealing Method | Heating element |
| Table Height | 805 mm |
| Power Supply | 230V, 50 / 60Hz, 1PH |
| Power Consumption | 1.0 kw |
| Layout Dimension | 1440.L x 600.W x 153.H mm |
